Product Description
·Durable pumps for fast and quiet operation.
·Sliding vane design provides sustained performance and trouble free operation, high reliability.
·Adjustable relief valve protects pump from excessive pressure.
Application:
·Fuel oil delivery truck
·Fleet refueling
·Lube oil
·Aviation refuelers
·Transport of Petrol Chemicals, gasoline, biofuels, solvents and many more.
Specifications
| Model | YB-50 | YB-65 | YB-80 | YB-100 |
| Size | 50mm/2" | 65mm/2.5" | 80mm/3" | 100mm/4" |
| Pump Speed | 400 - 640RPM | 400 - 640RPM | 400 - 640RPM | 500RPM |
| Max. Flowrate | 150 - 300L/min | 300 - 500L/min | 600 - 1000L/min | 1500 - 1900L/min |
| Motor Power | 2.2KW | 4KW | 7.5KW | 18.5KW |
| Vacuum | 0.5Bar |
| Working Pressure | 5Bar |
